Technical Parameters:

1. Detection procedure: level sensitivity adjustment, which can meet the needs of different occasions.

2. Personnel passing rate: more than 40 person-times per minute.

3. Power supply: 110-240V AC, 50/60Hz, power consumption: ≤18W.

4. Testing standard: one yuan coin
5. Display mode: 6-zone digital tube display
6. Working environment: -10℃ ~45℃, ≤95%RH.

7. Channel size: 1980 (height) * 700(width) * 500 (depth) mm
8. Dimensions: 2220 (height) * 820 (width) * 580 (depth) mm
9. Packing size: door panel: 2280*570*210mm (2 pieces/carton)
Main box: 770*530*260mm

Performance Features:
1.Accurate positioning: 6 overlapping mesh detecting areas, bilateral emission, bilateral receiving, can accurate positioning by detecting, visual display the zone of the target.
2.Microprocessor technology: electromagnetic waves produced by a microcomputer control circuit, scanrate can be precisely controlled scans. Set according to the needs of the control panel, make  sure to set sensitivity with flexibility, reliability and stability.
3.Sound and light alarm: 3 options for adjustable volume alarm sound: high, low, or no voice, adapted to  the use of different occasions.
4.Adjustable sensitivity for each zones: Each zone has 100 sensitivity level (0 to 99). Preset the size of the metal objects, can be avoid the false alarms such as coins, buttons, jewelry, belt buckles etc.
5.Digital pulse technology: Digital signal processing filter systems, have excellent anti-jamming capability.
6.Password protection: Only enter the correct password; you can set the sensitivity and other parameters. Password is 4-digits, it can be set by the user.
7.Counting Statistics: Count the quantity of the passed people and the times of alarm..
8.Harmless: harmless to the heart pacemakers in the human body, pregnant women, magnetic floppy disk, tape and etc.
9.Power Safety: The power is on the top of the main unit, higher water resistance.
10.Configuration waterproof gloves: not only can fix the door, but also water proof.
11.Waterproof: made of PVC composite material, better waterproof, fireproof, and shock resistance.
12.Easy installation: The system is integrated design, only takes 20 minutes to complete the installation or removal.
